Cleveland Dam's Western abutment is set in rock whereas the Eastern 'abutment' is a valley



The construction of a US$25M seepage control blanket at the Cleveland dam in Canada is due to start in March 2001. The potential for seepage and instability of the east abutment of the dam was first recognized in 1954 when the concrete dam was built. The western abutment is set in rock, but on the eastern side the buried rock valley is infilled with silt, sand, gravel and glacial till. It is hoped that the seepage control project will make the dam safer.

https://www.waterpowermagazine.com/features/featurethe-case-of-cleveland-dam/



"Cleveland dam is a 91m high concrete gravity structure set in a deep bedrock canyon. Full reservoir supply level is at el. 146m and the dam crest is at el. 149m. In 1992, the dam was upgraded to pass the Probable Maximum Flood (PMF) and to withstand the Maximum Design Earthquake (MCE) event.

The dam impounds a reservoir extending 4.5km to the north where the Upper Capilano river flows into the reservoir. Typically 0.5km wide, the reservoir surface area is 2.3km2 at full reservoir level. Flow is controlled at the dam by a radial gate spillway, two mid-level intakes and outlets, and two low-level outlets."



"The dam is constructed in a bedrock canyon on the west side of the valley. Immediately east of the canyon is a wide, deep buried valley that extends about 2km (eastward from the dam to the base of Grouse Mountain. The buried valley extends to below sea level and is infilled with a complex stratification of silt, sand, gravel and glacial till. The west canyon bedrock is hard, moderately jointed granodiorite and quartz diorite with numerous inclusions of older sedimentary and volcanic rocks."


**********************************
